Dormer S2153/8 7648648 Ball-Nosed End Mill 2FL 3/8 inch
MODEL 7648648
$90.00 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
DORMER
Coating
TiAlN
Coating property (CTP)
1
Connection diameter - fractional inch (DCON MS)
3/8
Connection diameter - millimeter (DCON MS)
9.53
Corner radius - fractional inch (RE)
3/16
Corner radius - inch (RE)
0.188
Cut length
Extra long
Cutting diameter - fractional inch (DC)
3/8
Cutting diameter - inch (DC)
0.375
Cutting diameter - millimeter (DC)
9.53
Cutting diameter tolerance class (TCDC)
ANSI +.000/-.002
Depth of cut maximum - fractional inch (APMX)
1.3/4
EDP number
7648648
Flute count (NOF)
2
Flute helix angle (FHA)
30
Material
HM
Material application
K - Cast iron, M - Stainless steel, P - Steel and cast steel, S - High-temperature alloys
MID number
7648648
Mill Profile
N - General Purpose Cutter Type for Low to High Resistance Materials
Ordering code ANSI
S2153/8
Overall length - fractional inch (OAL)
4"
Overall length - inch (OAL)
4
Overall length - millimeter (OAL)
101.6
Radial rake angle (GAMF)
10
Shank
Cylindrical shank
Dormer’s S215 2-flute ball nose slot drills have an extra long flute length for good rigidity and an aluminium titanium coating to prevent workpiece material from sticking to the cutting edges of the tool so you get a clean and accurate result.
Manufactured from premium carbide, the tools have a longer service life and excellent performance, whilst the ball nose geometry is designed for high performance contouring of complex surfaces.
S215 2-flute ball nose milling cutters can be used for plunging, ramping and profile milling in steel, stainless steels and cast iron
