Dormer S52518.0 6706818 Finishing End Mill 18.00 mm
MODEL 6706818
$437.73 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
DORMER
Coating
TiSiN
Coating property (CTP)
1
Connection diameter - inch (DCON MS)
0.7087
Connection diameter - millimeter (DCON MS)
18
Cut length
Short
Cutting diameter - inch (DC)
0.7087
Cutting diameter - millimeter (DC)
18
Cutting diameter tolerance class (TCDC)
h9
Depth of cut maximum - inch (APMX)
1.378
Depth of cut maximum - millimeter (APMX)
35
EDP number
46706818
Flute count (NOF)
8
Flute helix angle (FHA)
50
Material
HM
Material application
H - Hardened materials
MID number
6706818
Mill Profile
N - General Purpose Cutter Type for Low to High Resistance Materials
Neck diameter - inch (DN)
0.6693
Neck diameter - millimeter (DN)
17
Ordering code ANSI
S52518.0
Overall length - inch (OAL)
3.937
Overall length - millimeter (OAL)
100
Peripheral effective cutting edge count (ZEFP)
8
Radial rake angle (GAMF)
-26
Shank
Cylindrical shank DIN 6535 HA
Usable Length - millimeter (LU)
53
S525 carbide multi flute milling cutters are designed specifically for milling in non-ferrous materials such as aluminium.
For high performance profiling on CNC machines, the tools come with a 50 degree helix, whilst the multi flute feature provides high rigidity for finishing of profiles.
With a titanium silicon nitride coating for longer tool life and improved performance milling difficult to machine materials, the cutters are manufactured from premium carbide for great results and to further extend tool life
