Image for Illustration purposes only. Actual product may vary
Dormer S5276.0 6706830 Finishing End Mill 6.00 mm
MODEL 6706830
$109.29 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
DORMER
Coating
TiSiN
Coating property (CTP)
1
Connection diameter - inch (DCON MS)
0.2362
Connection diameter - millimeter (DCON MS)
6
Cut length
Extra long
Cutting diameter - inch (DC)
0.2362
Cutting diameter - millimeter (DC)
6
Cutting diameter tolerance class (TCDC)
h9
Depth of cut maximum - inch (APMX)
1.4961
Depth of cut maximum - millimeter (APMX)
38
EDP number
46706830
Flute count (NOF)
6
Flute helix angle (FHA)
50
Material
HM
Material application
H - Hardened materials
MID number
6706830
Mill Profile
N - General Purpose Cutter Type for Low to High Resistance Materials
Neck diameter - inch (DN)
0.2165
Neck diameter - millimeter (DN)
5.5
Ordering code ANSI
S5276.0
Overall length - inch (OAL)
3.937
Overall length - millimeter (OAL)
100
Peripheral effective cutting edge count (ZEFP)
6
Radial rake angle (GAMF)
-26
Shank
Cylindrical shank DIN 6535 HA
Usable Length - millimeter (LU)
60
One of Dormer’s extensive range of carbide milling cutters, S527 end mills have an extra long multi flute design, giving high rigidity for finishing of deep profiles, and are made specifically for finishing in hardened tool steels up to 63HRC.
The titanium silicon nitride coating means you get improved performance when milling difficult to machine materials, plus extended tool life.
Manufactured from premium carbide for superior performance and to further extend tool life, S527 application end mills are designed specifically for finishing in hardened tool steels up to 63HRC
