Image for Illustration purposes only. Actual product may vary
Dormer E5156-32NO6 5976861 UNC Machine Tap Straight Flute 3FL No.6 x 32
MODEL 5976861
$48.57 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
Basic Standard
ISO 529
Clamping Length - millimeter (LSC)
5
Clamping width - inch
0.1102
Clamping width - millimeter (WSC)
3.55
Coating
Bright
Coating property (CTP)
3
Connection diameter - inch (DCON MS)
0.1398
Connection diameter - millimeter (DCON MS)
50
Coolant supply property (CSP)
2.8
EDP number
154120
Flute count (NOF)
2.85
Flute Geometry (FDC)
Straight Flute Geometry
Hand (Cutting direction)
Right
Material
HSS
Material application
N - Non-ferrous metals, P - Steel and cast steel
MID number
5976861
Ordering code ANSI
E5156-32NO6
Overall length - inch (OAL)
1.9685
Overall length - millimeter (OAL)
14
Premachined hole diameter - inch (PHD)
0.1122
Premachined hole diameter - millimeter (PHD)
2.85
Shank
Cylindrical shank with Square
Thread diameter - inch (TD)
0.138
Thread diameter - millimeter (TD)
3.505
Thread diameter size (TDZ)
6
Thread form (THFT)
UNC - Unified Coarse
Threading length - inch (THL)
0.5512
Threading length - millimeter (THL)
14
Threads per inch (TPI)
32
Usable length (ULDR)
1.5
Usable Length - inch (LU)
0.5512
Usable Length - millimeter (LU)
14
Set of straight flute hand taps NO6 for Unified National Coarse thread UNC 6 with 32 TPI and 2B class of fit, consisting of 1 tap with a 6-8xP taper lead, 1 tap with a 4-6xP plug lead and 1 tap with a 2-3xP semi-bottoming lead, dimensions according to ISO 529 standard with 3.55mm shank and 2.8mm square drive, HSS with bright finish for 1.5xD through or blind hole threading in free machining steel and copper or copper alloys.
