Dormer E005M6 5974469 Machine Tap Spiral Point M6 x 1.00 mm
MODEL 5974469
$14.69 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
ANSI
Clamping width - inch
0.191
Coating
Bright
Connection diameter - inch (DCON MS)
0.255
Connection diameter - millimeter (DCON MS)
6.48
EDP number
580349
Flute count (NOF)
2
Flute Geometry (FDC)
Spiral Point Geometry
Hand (Cutting direction)
Right
Material
HSS-E-PM
Material application
N - Non-ferrous metals, P - Steel and cast steel
MID number
5974469
Ordering code ANSI
E005M6
Overall length - fractional inch (OAL)
2.1/2
Overall length - inch (OAL)
2.5
Overall length - millimeter (OAL)
0.255
Premachined hole diameter - imperial (PHD)
N9
Premachined hole diameter - inch (PHD)
0.1969
Premachined hole diameter - millimeter (PHD)
5
Shank
Cylindrical shank with Square
Tap chamfer style (TCS)
B 3.5 - 5
Thread diameter - millimeter (TD)
N9
Thread diameter size (TDZ)
6
Thread form (THFT)
M - Metric coarse
Thread pitch - inch (TP)
0.0394
Thread pitch - millimeter (TP)
1
Threading length - inch (THL)
0.5075
Tolerance limit
D5
Usable length (ULDR)
2.5
Usable Length - inch (LU)
1.0073
Spiral point tap with chamfer form B with a 3.5-5xP plug lead, for ISO-Metric thread M6 with 1.00 mm pitch and 6H class of fit, dimensions according to ANSI standard with 0.2550" shank and 0.1910" square drive, powder metallurgical HSS-E with bright finish for 2.5xD through hole threading in free machining and plain carbon steel and wrought or cast aluminium and copper or copper alloys.
