Dormer E0611.1/2NO6 5974855 Hand Tap Straight Flute 4FL 1.1/2 inch x 6
MODEL 5974855
$537.47 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
Basic Standard
ANSI
Clamping width - fractional inch (WSC)
1.233
Clamping width - inch
0.952
Coating
Bright
Coating property (CTP)
4
Connection diameter - inch (DCON MS)
6.3/8
Connection diameter - millimeter (DCON MS)
31.32
EDP number
259696
Flute count (NOF)
34
Flute Geometry (FDC)
Straight Flute Geometry
Hand (Cutting direction)
Right
Material
HSS
Material application
N - Non-ferrous metals, P - Steel and cast steel
MID number
5974855
Ordering code ANSI
E0611.1/2NO6
Overall length - fractional inch (OAL)
6.3/8
Overall length - inch (OAL)
6.375
Overall length - millimeter (OAL)
161.93
Premachined hole diameter - inch (PHD)
1.3386
Premachined hole diameter - millimeter (PHD)
1.11/32
Shank
Cylindrical shank with Square
Thread diameter size (TDZ)
1.1/2
Thread form (THFT)
UNC - Unified Coarse
Threading length - inch (THL)
1.87
Threads per inch (TPI)
6
Tolerance limit
H4
Usable length (ULDR)
1.5
Set of straight flute hand taps NO6 for Unified National Coarse thread UNC 1.1/2" with 6 TPI and 3B class of fit with H4 pitch diameter limits, consisting of 1 tap with a 6-8xP taper lead, 1 tap with a 4-6xP plug lead and 1 tap with a 2-3xP semi-bottoming lead, dimensions according to ANSI standard with 1.2330" shank and 0.9520" square drive, HSS with bright finish for 1.5xD through or blind hole threading in free machining and plain carbon steel and copper or copper alloys.
