Dormer E100M2.5NO8 5974696 M Hand Tap Straight Flute DIN 352 3FL M2.5 x 0.45 mm
MODEL 5974696
$37.16 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
Basic Standard
DIN 352
Clamping width - inch
0.0827
Clamping width - millimeter (WSC)
2.8
Coating
Bright
Coating property (CTP)
3
Connection diameter - inch (DCON MS)
0.1102
Connection diameter - millimeter (DCON MS)
40
Coolant supply property (CSP)
2.1
EDP number
78846
Flute count (NOF)
2.05
Flute Geometry (FDC)
Straight Flute Geometry
Hand (Cutting direction)
Right
Material
HSS
Material application
N - Non-ferrous metals, P - Steel and cast steel
MID number
5974696
Ordering code ANSI
E100M2.5NO8
Overall length - inch (OAL)
1.5748
Overall length - millimeter (OAL)
40
Premachined hole diameter - inch (PHD)
0.0807
Premachined hole diameter - millimeter (PHD)
2.05
Shank
Cylindrical shank with Square
Tap chamfer style (TCS)
A 6 - 8 / B 3.5 - 5 / C 2 - 3
Thread diameter size (TDZ)
2.5
Thread form (THFT)
M - Metric coarse
Thread pitch - inch (TP)
0.0177
Thread pitch - millimeter (TP)
0.45
Threading length - inch (THL)
0.3543
Threading length - millimeter (THL)
9
Usable length (ULDR)
1.5
Set of straight flute serial taps NO8 for ISO-Metric thread M2.5 with 0.45 mm pitch and 6H class of fit, consisting of 1 tap with a truncated thread profile and 6-8xP taper lead, 1 tap with a truncated thread profile and 3.5-5xP plug lead and 1 tap with a 2-3xP semi-bottoming lead, dimensions according to DIN 352 standard with 2.8mm shank and 2.1mm square drive, HSS with bright finish for 1.5xD through or blind hole threading in free machining and plain carbon steel and non-ferrous metals.
