HX18N22 5995791 Purple/Bronze 135° Jobber Drill N22
MODEL 5995791
This product has a minimum order quantity of (12 minimum) This is the minimum order quantity available when purchasing this product.
$2.33 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity(12 minimum)
Typically Ships in: 1 day
Returnable: Yes
ApplicationAngleIcon_DICT_SEL
Drill point 135°
Basic Standard
ANSI
Coating
Purple/Bronze
Connection (shank) description
Cylindrical shank
Cutting diameter (wire gauge size) (DC)
N22
Cutting diameter - inch (DC)
0.157"
Cutting diameter - millimeter (DC)
3.99
Drill Length
Jobber
Hand (Cutting direction)
Right
Length chip flute - fractional inch (LCF)
2
Material
HSS
Overall length - fractional inch (OAL)
3.1/8
Overall length - millimeter (OAL)
79.38
Point Angle (SIG)
135
Spiral form
Standard Spiral
Surface treatement
Steam Tempered
Usable length (ULDR)
4
Manufactured from premium High Speed Steel for drilling all types of steel, HX18 heavy duty jobber dill bits are your go-to jobber drill.
The HX18 come in wire gauge sizes from 52 to 1, and are suitable for use in both machine and hand-held applications.
The 135 degree split point is a great aid to self-centering and reduces the push force needed to drill into the workpiece.
As a final touch, HX18 jobber drill bits have a dual steam oxide coat.
This prevents workpiece material from sticking to the cutting edges of the drill to give you a cleaner, more accurate hole.
