QC1290P23/64 5996429 135° Extra Length Drill ANSI 23/64 inch
MODEL 5996429
$84.55 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
Application Material
K - Cast iron, P - Steel and cast steel
ApplicationAngleIcon_DICT_SEL
Drill point 135°
Basic Standard
ANSI
Coating
Bright
Connection (shank) description
Cylindrical shank
Cutting diameter - fractional inch (DC)
23/64"""
Cutting diameter - inch (DC)
0.3594
Cutting diameter - millimeter (DC)
9.13
Drill Length
XL
Hand (Cutting direction)
Right
Length chip flute - fractional inch (LCF)
9"
Material
HSS
Overall length - fractional inch (OAL)
12
Overall length - millimeter (OAL)
304.8
Point Angle (SIG)
135
Spiral form
Quick Spiral
Surface treatement
Original surface
Usable length (ULDR)
10
QC1290P extra length drills are all manufactured with a 12 inch overall length for extra reach. They also have a specially designed parabolic flute which makes it possible to drill deeper holes in a single pass – no pecking.
Manufactured from premium High Speed Steel, the drills are suitable for drilling a wide range of materials including steels, stainless steel and aluminum, and the bright finish prevents workpiece material from sticking to the cutting edges of the tool for a cleaner, more accurate hole.
For help with self centering, the tools have a 135 degree split point, which also reduces the force needed to drill into the workpiece.
QC1290P extra length drills come in a range of metric diameters from 1/8 inch to 1/2 inch in 1/64 inch increments.
