Precision Twist Drill DCN6, part number 6002384, 7/32" (0.2188") solid carbide center drill with bright finish and 60° point. Cylindrical shank, 1/2" connection diameter, 3" overall length, right-hand cut. Precision standard for center drilling 60° applications.

Name: Precision Twist Drill DCN6, part number 6002384, 7/32" (0.2188") solid carbide center drill with bright finish and 60° point. Cylindrical shank, 1/2"
Brand: Precision Twist Drill
Price: 168.0 USD
Availability: InStock
Rating: 5.0 (1 reviews)

MODEL 6002384

BRAND

Precision Twist Drill

SKU

6089419

WEIGHT

0.232 lb

UOM

each

$168.00 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

ApplicationAngleIcon_DICT_SEL

Center drilling 60°

Basic Standard

Precision

Coating

Bright

Connection diameter - fractional inch (DCON MS)

1/2

Connection diameter - inch (DCON MS)

0.5

Connection diameter - millimeter (DCON MS)

12.7

Cutting diameter - fractional inch (DC)

7/32"

Cutting diameter - inch (DC)

0.2188

Cutting diameter - millimeter (DC)

5.56

Hand (Cutting direction)

Right

Internal designation number

Length chip flute - fractional inch (LCF)

7/32

Material

Overall length - fractional inch (OAL)

Overall length - millimeter (OAL)

76.2

Shank

Cylindrical shank

Step included angle (STA)

Usable length (ULDR)

Centre drill (combined drill and countersink) with 60° straight conical form, double ended and cylindrical body, size 6 with 7/32" drill diameter, a body diameter of 1/2" and an overall length of 3", according to Precision standard to produce form A centre holes, solid carbide and bright finish for machining free machining, plain carbon, alloy and tool steel, grey, malleable, ductile, austenitic or austempered ductile and compacted graphite cast-iron, wrought and cast aluminium, copper or copper alloys and polymers.
