15285-44H23FLNO1 6007315 Hand Tap No.5 x 44
MODEL 6007315
$5.90 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
ANSI
Clamping width - inch
0.11
Coating
Bright
Connection diameter - inch (DCON MS)
0.141
Connection diameter - millimeter (DCON MS)
3.58
Flute count (NOF)
3
Flute Geometry (FDC)
Straight Flute Geometry
Hand (Cutting direction)
Right
Material
HSS
Overall length - fractional inch (OAL)
1.15/16
Overall length - inch (OAL)
1.9375
Shank
Cylindrical shank with Square
Thread diameter size (TDZ)
5
Thread form (THFT)
UNF - Unified Fine
Threading length - fractional inch (THL)
5/8
Threads per inch (TPI)
44
Tolerance limit
H2
Usable length (ULDR)
1.5
Straight flute hand tap NO1 with a 6-8xP taper lead, for Unified National Fine thread UNF 5 with 44 TPI and 2B class of fit with H2 pitch diameter limits, dimensions according to ANSI standard with 0.1410" shank and 0.1100" square drive, HSS with bright finish for 1.5xD through or blind hole threading in general purpose applications.
