PXU21A30

Image for Illustration purposes only. Actual product may vary

View in markdown

Red Lion PXU21A30 PXU PID temperature controller with 1/8 DIN form factor. Features solid state relay output, RS-485 communication, and universal AC power input. Designed for industrial heat/cool process control applications requiring precise temperature regulation.

MODEL PXU21A30

SKU

2302965

UOM

each

Contact supplier for technical support on: 717 767 6511 x2

Click for 5% off

$215.00 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: See conditions

Specifications:

  • PID Control
  • Main Control Output - Solid State Relay
  • Secondary Control Output - Relay
  • RS-485 Communications
  • 2 Programmable User Inputs
  • Accepts TC and RTD
  • Accepts 0-10 V, 0/4-20 mA or 0-50 mV Signals
  • On Demand Auto-Tuning of PID Settings
  • 2 User Programmable Function Buttons
  • Dual Relay Alarm
  • PC or Front Panel Programming
  • 1/8 DIN Size
  • Controllers Meet IP65 Requirements
  • 100 to 240 VAC Power Input

SKU: 286716

Arived with the readout actully working

This one worked. Second one I ordered, one from another supplier. First one was dead. Battery is supposed to last for 5 years, it's an "always on" setup. Mine first one did last the 5 years. I use this on my milling machine powered by a VFD.

Read more
