Image for Illustration purposes only. Actual product may vary
Red Lion PXU31A30 is a 1/8 DIN PID temperature controller with a 20mA analog output, relay output, and RS-485 communication. It features universal input for thermocouple, RTD, and process signals. The controller is designed for industrial heat/cool process control applications.
MODEL PXU31A30
Contact supplier for technical support on: 717 767 6511 x2
$215.00 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: See conditions
Specifications:
PID Control
Main Control Output - 4 to 20mA
Secondary Control Output - Relay
RS-485 Communications
2 Programmable User Inputs
Accepts TC and RTD
Accepts 0-10 V, 0/4-20 mA or 0-50 mV Signals
On Demand Auto-Tuning of PID Settings
2 User Programmable Function Buttons
Dual Relay Alarms
PC or Front Panel Programming
1/8 DIN Size
Controllers Meet IP65 Requirements
100 to 240 VAC Power Input
SKU: 286716
Arived with the readout actully working
This one worked. Second one I ordered, one from another supplier. First one was dead. Battery is supposed to last for 5 years, it's an "always on" setup. Mine first one did last the 5 years. I use this on my milling machine powered by a VFD.
