Pramet HZ/2 14-14 H7:333TN 6755460 Broaching Insert
MODEL 6755460
This product has a minimum order quantity of (2 minimum) This is the minimum order quantity available when purchasing this product.
$172.96 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity(2 minimum)
Typically Ships in: 1 day
Returnable: Yes
Chipbreaker
No chipbreaker
Coating
333TN
Coating process
PVD
Coating property (CTP)
1
Cooling effect
Very positive effect on tool life - cooling is recommended
Cutting width - inch (CW)
0.551
Cutting width - millimeter (CW)
14
Cutting width lower tolerance - inch (CWTOLL)
0
Cutting width lower tolerance - millimeter (CWTOLL)
0
Cutting width upper tolerance - inch (CWTOLU)
0.001
Cutting width upper tolerance - millimeter (CWTOLU)
0.018
Depth of cut maximum - inch (APMX)
0.315
Depth of cut maximum - millimeter (APMX)
8
Feed maximal - millimeter
0.3
Feed minimal - millimeter
0.08
Feed_MAX_IMP_NUM
0.012
Feed_MIN_IMP_NUM
0.003
Insert length - inch (INSL)
1.417
Insert length - millimeter (INSL)
36
Insert shape code (SC)
H - hexagonal
Insert thickness - inch (S)
0.547
Insert thickness - millimeter (S)
13.9
Insert thickness total - inch (S1)
0.551
Insert thickness total - millimeter (S1)
14
Double ended keyway and slotting insert for broaching a width of 14mm within tolerance class H7, grade 333TN PVD coated HSS within ISO-grade ranges P45-P50 for machining of steel in combination with a PHZ-2…-14 size broach
