MROSupply Has Hundreds Of Brands, Millions Of Products, Including
Image for Illustration purposes only. Actual product may vary
Pramet RPET 1505MOS-M:M8330 7447965 Milling Insert - Copy And Profile
MODEL 7447965
This product has a minimum order quantity of (10 minimum) This is the minimum order quantity available when purchasing this product.
$14.54 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity(10 minimum)
Typically Ships in: 1 day
Returnable: Yes
Chipbreaker
M
Coating
M8330
Coating process
PVD
Coating property (CTP)
1
Cooling effect
Slightly negative effect on tool life
Depth of cut maximum - inch (APMX)
0.138
Depth of cut maximum - millimeter (APMX)
3.5
Depth of cut minimum - inch (APMN)
0.02
Depth of cut minimum - millimeter (APMN)
0.5
Feed maximal - millimeter
0.5
Feed minimal - millimeter
0.12
Feed_MAX_IMP_NUM
0.02
Feed_MIN_IMP_NUM
0.005
Fixing hole diameter - inch (D1)
0.217
Fixing hole diameter - millimeter (D1)
5.5
Insert diameter - inch (INSD)
0.621
Insert diameter - millimeter (INSD)
15.785
Insert shape code (SC)
R - round
Insert thickness - inch (S)
0.219
Insert thickness - millimeter (S)
5.56
Single-sided milling insert RPET 1505 with chip-breakers, round for a maximum depth of cut of 3.5mm, with an indexing accuracy according to ISO-tolerance class-E and M geometry with rounded cutting edges and facet, M8330 PVD coated fine grained WC-Co carbide within ISO-grade range P20-P40 for machining of steel with face mills SOD06D
