Pramet 125B9R-S90AP16D 6757031 Shell Milling Cutter - Square Shoulder
MODEL 6757031
$1,025.14 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
Axial rake angle (GAMP)
6
Clamping Type Code (MTP)
Screw clamping through hole
Connection diameter - inch (DCON MS)
1.575
Connection diameter - millimeter (DCON MS)
40
Counterbore diameter connection bore - inch (DCCB)
2.205
Counterbore diameter connection bore - millimeter (DCCB)
60
Cutting diameter - inch (DC)
4.921
Cutting diameter - millimeter (DC)
125
Cutting pitch differential (CPDF)
1
Functional length - millimeter (LF)
63
Hand (Cutting direction)
Right
Insert index count (NOI)
9
Keyway depth - millimeter (KWD)
9
Keyway width - millimeter (KWW)
16.4
Overall length - inch (OAL)
2.48
Overall length - millimeter (OAL)
63
Peripheral effective cutting edge count (ZEFP)
9
Radial rake angle (GAMF)
0
Rotational speed maximum (RPMX)
7500
Shank
Shell mill DIN 8030 B
Shoulder mill with positve/negative geometry which utilises 9 off APKT 1604.. or APET 1604.. single-sided inserts, cutting diameter 125mm with 90° approach angle and 40mm connection bore according to DIN 8030-B, 63mm protrusion length and differential pitch for shallow shoulder milling, shallow slot milling, ramping, helical milling, plunge milling and progressive plunge milling with a maximum depth of cut of 13.0mm
