Pramet 40A3R045A32-SVC22C 6757990 End Milling Cutter - Copy and Profile
MODEL 6757990
$481.21 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
Axial rake angle (GAMP)
3
Clamping Type Code (MTP)
Screw clamping through hole
Connection diameter - inch (DCON MS)
1.26
Connection diameter - millimeter (DCON MS)
32
Coolant supply property (CSP)
1
Cutting diameter - inch (DC)
1.575
Cutting diameter - millimeter (DC)
40
Hand (Cutting direction)
Right
Insert index count (NOI)
3
Overall length - inch (OAL)
5.906
Overall length - millimeter (OAL)
150
Peripheral effective cutting edge count (ZEFP)
3
Radial rake angle (GAMF)
8
Rotational speed maximum (RPMX)
9300
Shank
Cylindrical shank DIN 1835A
Usable Length - millimeter (LU)
45
End mill with double positive geometry which utilises 3 off VCGT 220530F-FA single-sided inserts, cutting diameter 40mm with 90° approach angle and 32mm parallel shank according to DIN 1835A, 150mm overall length, through coolant for helical milling and progressive plunge milling with a maximum depth of cut of 3.0 (16.0)mm
