Pramet PSR3-R12:T9335 6803683 Scarfing Ring
MODEL 6803683
This product has a minimum order quantity of (10 minimum) This is the minimum order quantity available when purchasing this product.
$34.84 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity(10 minimum)
Typically Ships in: 1 day
Returnable: Yes
Application Material
P - Steel and cast steel
Chipbreaker
No chipbreaker
Coating
T9335
Coating process
MT-CVD
Coating property (CTP)
1
Insert cutting diameter - inch (CDI)
0.433
Insert cutting diameter - millimeter (CDI)
11
Insert diameter - inch (INSD)
0.8661
Insert diameter - millimeter (INSD)
22
Insert shape code (SC)
P - pentagonal
Insert thickness - inch (S)
0.394
Insert thickness - millimeter (S)
10
Inside tube diameter maximum - millimeter
34
Inside tube diameter minimum - millimeter
30
Profile radius - millimeter (PRFRAD)
12.5
Scarfing ring with an outside diameter of 22mm, an inside diameter of 11mm, 10mm thick and a working radius of 12.5mm for tube diameters from 30 to 34mm, T9335 MT-CVD coated functionally graded WC-Co carbide within ISO-grade ranges P20-P45 and M15-M40 for deburring the inside of steel and stainless-steel tubes and pipes
