Dormer A2423.0X10.0 47191820 118° Center Drill - 60D 3.00 mm x 10.00 mm
MODEL A2423.0X10.0
This vendor has a minimum order quantity of 4. Order minimum ($) may be applied. Add desired QTY to cart and proceed to checkout to view minimum
$22.01 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity
Orders over $500 qualify for a Free Gift
Brand Minimum Order Quantity: 4
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningStill Deciding?
Add this item to your saved items and easily come back later.
Application Material
P - Steel and cast steel
Usable length (ULDR)
1
Material
HSS-E
Surface treatement
Original surface
Shank
Cylindrical shank
Point Angle (SIG)
118
Connection diameter - millimeter (DCON MS)
10
Coating
Bright
Overall length - millimeter (OAL)
100
Hand (Cutting direction)
Right
Cutting diameter - millimeter (DC)
3
Material application
K - Cast iron, P - Steel and cast steel
Basic Standard
DORMER
Step included angle (STA)
60
Cutting diameter - inch (DC)
0.1181
MID number
7191820
EDP number
47191820
Ordering code ANSI
A2423.0X10.0
Centre drill (combined drill and countersink) with 60° straight conical form, double ended and cylindrical body, 3.00mm drill diameter, a body diameter of 10.00mm and an overall length of 100mm, according to DORMER standard to produce standardized centre holes according DIN 332 part 1 form A, cobalt based HSS-E and bright finish for machining free machining, plain carbon and alloy steel and grey cast-iron.
