Dormer C92218.0 5985117 Roughing End Mill 18.00 mm
MODEL 5985117
$145.68 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
DIN 844 K
Coating
ALCRONA
Coating property (CTP)
1
Connection diameter - inch (DCON MS)
0.6299
Connection diameter - millimeter (DCON MS)
16
Cut length
Short
Cutting diameter - inch (DC)
0.7087
Cutting diameter - millimeter (DC)
18
Cutting diameter tolerance class (TCDC)
k12
Depth of cut maximum - inch (APMX)
1.2598
Depth of cut maximum - millimeter (APMX)
32
EDP number
150856
Flute count (NOF)
3
Flute helix angle (FHA)
35
Material
HSS-E-PM
MID number
5985117
Mill Profile
HRA - Fine Pitch Asymmetrical Rounded Profile Chipbreaker
Neck diameter - inch (DN)
0.6102
Neck diameter - millimeter (DN)
15.5
Ordering code ANSI
C92218.0
Overall length - inch (OAL)
3.622
Overall length - millimeter (OAL)
92
Peripheral effective cutting edge count (ZEFP)
3
Radial rake angle (GAMF)
12
Shank
Weldon shank DIN 1835B
Usable Length - millimeter (LU)
43.5
C922 3-flute milling cutters from Dormer are designed for roughing and can be used when plunging, ramping and profile milling.
They are manufactured from powder metal High Speed cobalt, with the improved performance and longer tool life you would expect.
Further increasing the life of the tools, the Alcrona coating also improves performance with CNC machines when milling difficult to machine materials.
Also for CNC machines, the 35 degree helix is yet another boost to performance and is also designed to reduce vibration.
C922 roughing end mills come with a medium length flute with an HRA profile.
This breaks up the chips for efficient roughing application and is suitable for milling steels, stainless steels and cast iron
