Dormer B44210.0 5987200 Machine Reamer Extremely Unequal Spacing 6FL 10.00 mm
MODEL 5987200
$153.50 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningAchievable hole tolerance (TCHA)
H7
Basic Standard
DIN 8051
Body length - millimeter (LB)
102.5
Coating
Bright
Connection size code machine side (CZC MS)
MK 1
Cutting diameter - inch (DC)
0.3937
Cutting diameter - millimeter (DC)
10
EDP number
421185
Flute count (NOF)
6
Hand (Cutting direction)
Right
Length chip flute - millimeter (LCF)
19
Material
HM
Material application
K - Cast iron, N - Non-ferrous metals, P - Steel and cast steel
MID number
5987200
Ordering code ANSI
B44210.0
Overall length - inch (OAL)
6.6142
Overall length - millimeter (OAL)
168
Shank
Morse Taper Shank
Machine reamer with straight flutes which are extremely unequally spaced and a Morse taper shank, diameter 10.00mm with an overall length of 168mm, a flute length of 19mm and 102.5mm reach with neck relief, according to DIN 8051 standard for reaming precise holes within H7 tolerance, solid carbide with bright finish for machining free machining, plain carbon, alloy and tool steel, grey, malleable, ductile and compacted graphite cast-iron, wrought and cast aluminium and copper or copper alloys.
