Danfoss 131B1153 FC-302P15KT5E21H2XGXXXXSXXXXAXBXCXXXXDX
MODEL 131B1153
Contact supplier for technical support on: 888 326 3677
$3,561.36 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
| Specification | Value |
|---|---|
| Product Group | VLT® AutomationDrive FC- |
| Series | 302 |
| Power Rating | 7.5 KW / 10 HP |
| Phase | Three phase |
| Mains Voltage | 380 - 500 VAC |
| Enclosure | IP20 / Chassis |
| RFI Filter | H2 |
| Brake - Safe Stop | Brake chopper |
| LCP | Graphical Loc. Cont. Panel |
| Coating PCB | Not coated PCB |
| Mains Option | No Mains Option |
| Adaptation A | Standard Cable Entry |
| Adaptation B | No adaptation |
| Software Release | Latest release std. SW. |
| Software Language Pack | Standard Language Pack |
| A Option | No A Option |
| B Option | No B Option |
| C0 Option MCO | No C0 option |
| C1 Option | No C1 option |
| C Option Software | No software option |
| D Option | No D option |
| Frame Size | A3 |
| Power 160% (HO) [KW] | 7.5 |
| Height [mm] | 268.0 |
| Width w/ no C options [mm] | 130.0 |
| Width w/ one C option [mm] | 170.0 |
| Width w/ two C options [mm] | 190.0 |
| Depth [mm] | 205.0 |
| Depth with Option A/B [mm] | 220.0 |
| Calculated Net Weight [kg] | 6.06 |
| Continuous Current (HO) [A] 3x380-440VAC | 16 |
| Intermittent Current (HO) [A] 3x380-440VAC | 25.6 |
| Continuous Current (HO) [A] 3x440-500VAC | 14.5 |
| Intermittent Current (HO) [A] 3x440-500VAC | 23.2 |
| Power Loss HO [W] 3x380-440VAC | 225 |
| Power Loss HO [W] 3x440-500VAC | 225 |
| kVA | 11.1 |
